導體: GB/T 3956 第1種或第2種導體
絕緣: XLPE交聯聚乙烯絕緣
金屬屏蔽: 銅帶繞包屏蔽(1.8/3kV)
外護套: 聚氯乙烯PVC、聚乙烯PE、聚烯烴
| 型號Type | 名稱Designation |
| YJV YJLV | 銅芯或鋁芯交聯聚乙烯絕緣聚氯乙烯護套電力電纜 Power cable with Cu/Al conductor,XLPEinsulation and PVCsheath |
| YJY YJLY | 銅芯或鋁芯交聯聚乙烯絕緣聚乙烯護套電力電纜 Power cable with Cu/Al conductor,XLPE insulation and PE sheath |
| 型號 Type |
芯數 No.of cores |
額定電壓Rated Voltage(kV) | |
| 0.6/1 | 1.8/3 | ||
| 導電線芯標稱截面mm²Normal cross sectional area of conductor mm² | |||
| YJV YJLV YJY YJLY | 1、2、3、4、5、3+1、3+2、4+1 | 1.5~630 | 10~630 |
